5PIN 光控底座
PRODUCT DESCRIPTION:The ANSI C136.41 compliant dimming receptacle and spring leaf contacts provides an electrical andmechanical interconnection between an ANSI C136.41-2013 photo control cell and luminaire.Ideal for outdoor commercial and utility lig
联系电话
vitop@vitop-mould.com 0577-62581788
vitop@vitop-mould.com 0577-62581788
产品详情
PRODUCT DESCRIPTION:
The ANSI C136.41 compliant dimming receptacle and spring leaf contacts provides an electrical and
mechanical interconnection between an ANSI C136.41-2013 photo control cell and luminaire.
Ideal for outdoor commercial and utility lighting, the ANSI C136.41 compliant dimming receptacle
is available with two or four dimming contacts to support either 0-10 VDC dimming methods
or Digital Addressable Lighting Interface (DALI), while providing a reliable power interconnect
with three robust twist lock contacts.
